Our Products
GLOSTER FIBER
CNC System
- Axis Travel : 130 mm x 130 mm x 70 mm
- Resolution : 2 Micron
- Accuracy : 2 Micron / 25 mm
- Repeatability : 2 Micron /25 mm Bidirectional
- Drive : Ac Servo
Dimensions
- Length x Width x Height : 900mm x 650 mm x 1500 mm
- Weight : 370kg
Electrical
- Power Requirement : 220 VAC +, 1 Phase, 50Hz
- Power Consumption : <2.5 KVA
- Room Temperature : 240 C - 260 C
Features
- Maintenance Free Machine
- 80 To 85% Saving in electricity bill
- No need of alignment and water filters
- No need of Rail, Rf, Power Supply and chiller
- Compact size machine
- Excellent cutting surface
Laser System
| No | Description | Parameter |
|---|---|---|
| 1 | Laser | Nd : YAG DPSSL |
| 2 | Spatial Mode | TEM00 |
| 3 | Wave Length | 1064 mm |
| 4 | Polarization | Linear |
| 5 | Beam Roundness | >90% |
| 6 | Average Power | >16 W |
| 7 | Repetition Rate | 6-12 KHz |
| 8 | Cooling Water | Steam Distilled |
FIBER-GLOSTER GALVO
CNC System
- Axis Travel : 130 mm x 130 mm x 70 mm
- Resolution : 2 Micron
- Accuracy : 2 Micron / 25 mm
- Repeatability : 2 Micron /25 mm Bidirectional
- Drive : Ac Servo
Dimensions
- Length x Width x Height : 900mm x 650 mm x 1500 mm
- Weight : 370kg
Electrical
- Power Requirement : 220 VAC +, 1 Phase, 50Hz
- Power Consumption : <2.5 KVA
- Room Temperature : 240 C - 260 C
Features
- Maintenance Free Machine
- 80 To 85% Saving in electricity bill
- No need of alignment and water filters
- No need of Rail, Rf, Power Supply and chiller
- Compact size machine
- Excellent cutting surface
Laser System
| No | Description | Parameter |
|---|---|---|
| 1 | Diamension | 66 cm x 67 cm x 157 cm (l x w x h) |
| 2 | Weight | 250Kg |
| 3 | Axis Travel | 130mm(x), 130mm(y), 75mm(z) |
| 4 | Laser Profile | Fiber laser source |
| 5 | Operating voltage | Single phase, 230V AC, 16 amp, 50/60 HZ4-18 watt |
| 6 | Output power | >24 watts |
IR-GLOSTER GALVO
CNC System
- Axis Travel : 130 mm x 130 mm x 70 mm
- Resolution : 2 Micron
- Accuracy : 2 Micron / 25 mm
- Repeatability : 2 Micron /25 mm Bidirectional
- Drive : Ac Servo
Dimensions
- Length x Width x Height : 1575mm x 900 mm x 1500 mm
- Weight : 390kg
Electrical
- Power Requirement : 220 VAC +, 50Hz, 1
- Power Consumption : 3 KVA, 15 Amp
Features
- We can cut any customize shape
- Ability to cut 10 to 12 crt rough size diamond in any shape.
- Highly accurate galvo cutting.
- We can cut round and fancy shape in same machine.
- Zero vibration due to heavy body weight.
- Highest installed machine in diamond industry.
- Masters for heavy tension diamonds.
Laser System
| No | Description | Parameter |
|---|---|---|
| 1 | Laser | Nd : YAG DPSSL |
| 2 | Wave Length | 1064 mm |
| 3 | Transverse Mode | TEM00 |
| 4 | CW Power | 75 Watt |
| 5 | Q-Switched Power | 25 Watt |
| 6 | Polarization | Linear |
| 7 | Beam Mode | M2 <1.2< /td> |
| 8 | Frequency Range | 1 to 20 Khz |
| 9 | Pluse Width | 100ns @ 7 khz |
IR - PINAK 4P
CNC System
- Axis Travel : 130 mm x 130 mm x 70 mm
- Resolution : 2 Micron
- Accuracy : 2 Micron / 25 mm
- Repeatability : 2 Micron /25 mm Bidirectional
- Drive : Ac Servo
Dimensions
- Axis Travel : 900mm x 650mm x 1500mm
- Weight : 370kg
Electrical
- Power Requirement : 220 VAC +, 1 Phase, 50Hz
- Power Consumption : 2.5 KVA
- Room Temperature : 240 C - 260 C
Features
- Only machine which delivers excel ent and accurate Fancy cutting.
- Capable to cut Fancy shapes with accurate dimensions.
- Accurate shape gives minimum polishing time and maximum Profit
- Minimum setting time and easy operation enab es fast production
- Dedicated parameters files for different shapes and sizes for easy operation
- Different faceting patterns for round shape.
- QR code reader for direct entry of parameters.
- Dedicated parameters fi es for different shapes and sizes for easy operation.
- Rugged and Heavy structure for minimum Vibrations
- Highest Up-time and Low maintenance cost.
Laser System
| No | Description | Parameter |
|---|---|---|
| 1 | Laser | ND-YAG DPSSL |
| 2 | Spatial Mode | TEM 00 |
| 3 | Wavelength | 1064 mm |
| 4 | Polarization | Linear |
| 5 | Beam Roundness | >90% |
| 6 | Average Power | >16 W |
| 7 | Repetition Rate | 6-12 KHz |
| 8 | Cooling Water | Steam Distilled + 10% Optishield |
SAW - MULTI
CNC System
- Axis Travel : 130 mm x 130 mm x 70 mm
- Resolution : 2 Micron
- Accuracy : 2 Micron / 25 mm
- Repeatability : 2 Micron /25 mm Bidirectional
- Drive : Ac Servo
Dimensions
- Length x Width x Height : 900mm x 650 mm x 1500 mm
- Weight : 370kg
Electrical
- Power Requirement : 220 VAC +, 1 Phase, 50Hz
- Power Consumption : <2.5 KVA
- Room Temperature : 240 C - 260 C
Features
- Capable to cut highly complexed planned diamond like Multi Pie,Pie ,Double side,Slicing.
- Consistent Results and Reliability.
- Exceptional Beam Quality gives lowest breakages.
- Polarization control allows to cut in any direction.
- Best model in Performance with attractive & sleek design in industry.
- Robust and sturdy structure for lowest vibration , minimum maintenance and high quality output.
- Industry proven Components for long terms stability
Laser System
| No | Description | Parameter |
|---|---|---|
| 1 | Laser | ND-YAG DPSSL |
| 2 | Spatial Mode | TEM 00 |
| 3 | Wavelength | 1064 mm |
| 4 | Polarization | Linear |
| 5 | Beam Roundness | >90% |
| 6 | Average Power | >16 W |
| 7 | Repetition Rate | 6-12 KHz |
| 8 | Cooling Water | Steam Distilled |
